PON Transceivers

GPON OLT SFP Transceivers

Product Features
Hot-pluggable SFP form factor
Wavelengths Tx1490nm/Rx1310nm
Transmission data rate Tx2.5G/RX1.25Gbps
Single Fiber SC receptacle
Reset burst-mode receiver design
Digital burst RSSI function to monitor the input optical power level
LVPECL compatible data input/output interface
LVTTL transmitter disable control
LVTTL transmitter laser fault alarm
LVTTL receiver Signal Detect (SD) indication
Digital Diagnostic Monitor Interface (DDM DOM)
Operating case temperature: 0 to 70 °C
RoHS 6 compliant
Applications
GPON OLT Class B+ 20Km transmission
  • USource GPON OLT SFP Transceivers is designed as per ITU G.984.2 Class B+ requirements for Optical Line Terminal (OLT) application.
    This optical modules incorporates a high performance 1310nm Burst Mode APD/TIA receiver and 1490nm Continuous Mode DFB transmitter with internal optical isolator.
    The optical modules built-in the 8472 I2C digital diagnostic interface monitor of its operating conditions and status,including transmitting power, laser bias current, module temperature ,supply voltage and the receiver power monitor(RSSI). Calibration and alarm/warning threshold data are written and stored in the internal memory(EEPROM).

    GPON SFP Transceivers
    Part No. Form ODN Class Data rate Wavelength Reach Receptacle
    UGP-L1 SFP Class B+ Tx2.5G/Rx1.25G Tx1490nm/Rx1310nm 20km SC
    UGP-L2 SFP Class C+ Tx2.5G/Rx1.25G Tx1490nm/Rx1310nm 20km SC
    UGP-N1S SFP GPON STICK Tx1.25G/Rx2.5G Tx1310nm/Rx1490nm 20km SC
  • Please submit your queries, Engineer will offer a quick and professional response!

    *

    *

    *

    *
